Attribute | Value |
---|---|
dn | 10 mm |
Dmax(S) | 209 mm |
Ds | 190 mm |
G1 | G1/2"-AG |
H | 66 mm |
LG1 | 18 mm |
SW1 | 32 mm |
Z (Stroke) | 8 mm |
Attribute | Value |
---|---|
Suction force | 1,050 N |
Volume | 165 cm³ |
Curve radius (min) (convex) | 350 mm |
Evacuation rate for pu = -0,6 bar | 30 l/min |
Size | 190 |
Number of folds | 0 |
Working temperature max. | 400 °C |
Suction cup material | Fluorocaoutchuc FPM-F |
Weight | 1,420 g |
Product family | SPL-HT |
