| Attribute | Value |
|---|---|
| dn | 13.5 mm |
| d2 | 111 mm |
| Dmax(S) | 177 mm |
| Ds | 150 mm |
| G1 | G1/2"-IG |
| H | 88.5 mm |
| LG1 | 13 mm |
| Z (Stroke) | 37.5 mm |
portant;">Note: Acceptable dimensional tolerances for rubber parts concerning to DIN ISO 3302-1 M3
portant;">
| Attribute | Value |
|---|---|
| Suction force | 570 N |
| Pull-off force | 1,000 N |
| Volume | 800 cm³ |
| Curve radius (min) (convex) | 250 mm |
| Hose diameter (empf.) d | 12 mm |
| Size | 150 |
| Nipple family | N 010 |
| Suction cup material | Nitrile rubber NBR |
| Material hardness [Shore A] | 70 |
| Weight | 801.5 g |
| Product family | TGAS |
| Number of folds | 1.5 |
portant;">Note: Suction force: The specified suction forces are theoretical values at a vacuum of -0.6 bar and with a smooth, dry workpiece surface - they do not include a safety factor Hose diameter: The recommended hose diameter refers to a hose length of approx. 2 m
